Lenco 12V 4 1/4″ Stroke Actuator with 6‘ Wire

Used with Troll’n Tab Kits prior to 2000
5/16″ (.79 cm) mounting hardware
Stroke: 4-1/4″ (10.8 cm)
Length overall: 14″ (35.56 cm)
Length pin to pin: 13″ (32.87 cm)
Diameter (upper housing): 2-1/2″ (6.35 cm)
Mounting hardware: 5/16″ (.79 cm) or Delrin Pin (Part #15087-001)

Part # (Superceded #)
# 15059-001 (102-2) 12 Volt w/6′ (1.83m) leads with Deutsch connectors and mounting hardware(replacement length)

• Top cap gland seal sheaths the actuator cable outer jacket as well as both internal conductors for maximum waterproofing
• Corrosion proof Vandar mounts
• Stainless steel ram won’t flex, even under extreme loads
• Double O-ring for maximum protection
• Ballscrew rotates freely on 12 ball bearings at both ends of its stroke so there’s no need for complicated limit switches and clutches
• Self-locking ballscrew locks into position and will not drift
• Precision molded, powdered metal, high alloy gears provide high accuracy, high wear resistance, and high strength for long life
• Tough, high-torque motor easily transfers 750 lbs
• High-impact, ultraviolet resistant nylon 66, 50% glass fiber reinforced thermoplastic housing
• Corrosion proof Vandar cap and mount, stands up to severe loads
